| technical data LIMA-400L:
|  |
| The drum volume amounts to approx.
|
400 litre |
| the drum length approx. |
1000 mm |
| the wrench width approx. |
700 mm |
| the filling weight approx. |
600 kg |
| the piece weight approx. |
30 kg |
| space under the drum:
|
| the height under the drum amounts to approx. |
760 mm |
| the depth under the drum approx. |
1300 mm |
| the width under the drum approx. |
1330 mm |
| setting up mass of the drum:
|
| the height of the machine amounts to approx. |
2000 mm |
| the depth of the machine approx. |
1500 mm |
| the width of the machine approx. |
3000 mm |
| machine remarks: |
the drum numbers of revolutions is alternatively after:
infinitely variable speed regulation or two fixed numbers of revolutions.
|
The drum execution are also after selection:
Manganese-, PUR-, rubber- , steel- , or sieve insert.
|
 |
